2-12-1
INSTINSTALLAALLATION TION INFOINFORMARMATIONTION
PRODUCT DIMENSIONSPRODUCT DIMENSIONS
Side ViewSide View
2525
11
/ 88
""
(64 cm)(64 cm)
33
22
11
2323
11
/ 22
""
(60 cm)(60 cm)
24"24"
(61 cm)(61 cm)
8383
11
/ 88
""
(211 cm)*(211 cm)*
33
11
/ 22
" (9 cm)*" (9 cm)*
1. 25-1/8" (64 cm) dimension is to front of top grille
2. Power cord (24") (61 cm)
3. 5 ft. (1.5 m) water line tubing taped to back
NOTE: (*) Dimensions shown are for leg level-
ers extended 1/8
″
(3 mm) below the rollers. For
levelers fully extended 1-1/4
″
(32 mm) below
the rollers, add 1-1/8
″
(29 mm) to this dimen-
sion.
Top ViewTop View
Model Width A
36
"
(91 cm)
42
"
(106 cm)
48
"
(122 cm)
35
"
(89 cm)
41
"
(104 cm)
47
"
(119 cm)
25-1/8"
(64 cm)
A
Front ViewFront View
8383
11
/ 88""
(211 cm)(211 cm)
AA
(see chart following)(see chart following)
Width of RefrigeratorWidth of Refrigerator
36
"
(91 cm)
42
"
(106 cm)
48
"
(122 cm)
36-1/4
"
(92 cm)
42-1/4
"
(107 cm)
48-1/4
"
(123 cm)
Model Width A (as shown above)
NOTE: The width dimensions shown represent
the distance from outside trim to outside trim.
