Kitchenaid Kssc36Fkb00 Page 30

Workshop Manuals
4-44-4
REMOVING A DOOR SWITCH, THE POWER SWITCH,REMOVING A DOOR SWITCH, THE POWER SWITCH,
THE INVERTER ASSEMBLY, ANDTHE INVERTER ASSEMBLY, AND
THE MAIN THE MAIN CONTROL BOARD ASSEMBLCONTROL BOARD ASSEMBLYY
NOTE: Sharp edges may be present.
1.Unplug the refrigerator or disconnect the
power.
2.Remove the main and louvered decora-
tive panels (see page 4-2).
Electrical Shock HazardElectrical Shock Hazard
Disconnect power before servicing.Disconnect power before servicing.
Replace all panels before operating.Replace all panels before operating.
Failure to do so can result in death or Failure to do so can result in death or
electrical shock.electrical shock.
Hex-Head Bolts
Bracket
b)Remove the two hex-head screws from
the door switch cover and remove the
cover.
Door Switch Cover Screw (1 of 2)
c)Disconnect the wire connectors from
the door switch terminals.
d)Press in on the locking arms and push
the switch out of the bracket.
Wire Connectors
Locking Arm
Door Switch
3.To remove a door switch (Original De-To remove a door switch (Original De-
sign):sign):
a)Remove the two hex-head bolts from
the door switch bracket and turn the
bracket over.
Power Switch
Main Control Board Assembly
Inverter Assembly
