1-31-3
MODEL & SERIAL NUMBER DESIGNATIONSMODEL & SERIAL NUMBER DESIGNATIONS
MODEL NUMBERMODEL NUMBER
SERIAL NUMBERSERIAL NUMBER
MMOODDEEL L NNUUMMBBEERR KSKSSS4SS4 22QQKKXX0000
PRODUCT GROUPPRODUCT GROUP
K = KitchenAid Brand
PRODUCT IDENTIFICATIONPRODUCT IDENTIFICATION
BR = Bottom Mount Right Hand Hinge
BL = Bottom Mount Left Hand Hinge
SS = Side-By-Side Built-In
MERCHANDISING SCHEME/SERIESMERCHANDISING SCHEME/SERIES
C = Wrap Around Stainless Steel
P = Factory Installed Panel Kit
S = Framed Trim Kit (Panels Not Included)
CAPACITY/ SIZECAPACITY/ SIZE
36 = 36
″
Width
42 = 42
″
Width
48 = 48
″
Width
FEATURESFEATURES
D = Ice & Water Dispensing
F = Factory Installed Ice Maker w/Filter
M = Factory Installed Ice Maker wo/Filter
Q = Ice/Crushed Ice & Water Dispensing w/Filter
YEAR OF INTRODUCTIONYEAR OF INTRODUCTION
K = 2001
COLOR CODECOLOR CODE
X = No Color Used
ENERGY ENERGY POWER POWER CONSUMPTION CHANGECONSUMPTION CHANGE
0 = Original, 1 = 1st Change, 2 = 2nd Change, Etc.
ENGINEERING CHANGE (NUMERIC)ENGINEERING CHANGE (NUMERIC)
0 = Original, 1 = 1st Change, 2 = 2nd Change, Etc.
SSEERRIIAAL L NNUUMMBBEERR QQLL33001100000033
MANUFACTURING SITEMANUFACTURING SITE
Q = LaVergne, TN
YEAR OF PRODUCTIONYEAR OF PRODUCTION
L = 2001
WEEK OF PRODUCTIONWEEK OF PRODUCTION
30th WEEK
PRODUCT SEQUENCE NUMBERPRODUCT SEQUENCE NUMBER
