TROUBLESHOOTING

1. Water will be automatically supplied to the Ice Maker depending on temperature & time conditions, and

ice will be produced to dispense.

2. Power is applied to one end of the wires. So, make sure to refer to its Exploded View whenever doing

the disassembly.

3. The operation of the Ice Maker shall be done after pressing the Ice Maker Test Button.

(Freezer Ice Maker) It is not possible to check when the power is off.

4. Since both of the PCB and the Ice Maker are located at the front and the back each other, make sure

to have two people check them.

4-2-3. When ICE MAKER(FZ) does not operate

ERROR Code

Opration Condition while Motor is rotating

Micom(IC01) Operation Status

Stand-by On

Motor CW Rotation (#54)

0V 5V

Motor CCW Rotation (#53)

0V 5V

Its operation status changes as the Motor

rotates CW or CCW.

Start

Upon the initial power on, is

there a self-diagnostic location

detection of the Ice Maker?

Ice Maker rotates when

pressing the Ice Maker testing

switch?

Input Voltage of IC01 MICOM

#78 is normal?

Is water supplied after a certain

time passes?

Is the ICE Maker Sensor

normal?

1) Check Wire Connection

2) Check & Replace ICE MAKER KIT

Check & Replace ICE MAKER KIT

1) Check Wire Connection

2) Check & Replace ICE MAKER KIT

3) Check & Replace MAIN PCB

1) Check & Replace Water Valve

* Refer to Water Valve Operating

Conditions

1) Replace or Repair ICE Maker

* Refer to it when ICE Maker Sensor is

defective

PCB & Ice Maker Related Parts are

normal.

Check the room temperature

Micom(IC01) Operation Status

Stand-by Rotation

Back

Rotation

Return

Rotation

Stand-by

#78

5V 0V 5V 0V 5V

Micom(IC01) Operation Status

#76

(Test Switch)

Stand-by On

5V 0V

Yes
