TROUBLESHOOTING
1. Water supplies to the Ice Maker automatically and ice is to be scooped out depending on its temperature and the timing.
2. Power is always applied to the Ice Maker. So, refer to the disassembly section to remove it.
3. To check the operation of the Ice Maker, press the Ice Maker Test Switch .before disassembling it. It is not possible to check its
operation after disconnecting its power.
4. The PCB and the Ice Maker are located at the back and at the front. So, if possible, check it with a team of two technicians.
5. When the Ice Maker Heater is on, it may cause personal injury. So, take extra care while working with the Ice Maker.
1) Check and replace Water Valve
*
Refer to Water Valve operating
conditions
2) Replace MAIN PCB
1) Check and replace Water Valve
*
Refer when Ice Maker Sensor is
defective
No
No
Yes
Yes
Is water supplied within 6
minutes (after Ice Full and
Parallel Detection)?
ICE Maker Sensor itself is in
good condition?
Start
1) Check and Replace ICE MAKER KIT
2)
Check Main PCB Input Signal /
Replace the Main PCB
(CN90 #5 - "0V")
1) Check after connecting the Wire
Harness
2) Check and Replace ICE MAKER KIT
3) Replace MAIN PCB
PCB and other parts are normal,
Check again the Connector contact
No
No
Yes
Yes
Operation Status (CN90 #5)
Test Switch
Stand-by
On
5V
0V
Micom (IC01) Operation Status
Stand-
by
Rotation
Before
completing
Home
CN52 #6
(Blade Ice
Scoop)
0V
4.9V 4.9V 0V
CN90 #4
(Guide Ice
Full)
0V 0V 4.9V 0V
Operation Condition upon Motor Rotation,
Operation Status of Micom (IC01)
Stand-
by
On
Motor Load (#72, #73) 0V 5V
Heater Load (#28) 0V 5V
Heater operates differently according to its
conditions. During the Test Mode, it will be on
30 seconds.
When pressing the Ice Maker
Test Switch (over 1.5 sec), does
it rotate?
Voltages at IC01 CN52 #6 and
CN90 #4 are normal?
4-2-10. When the ICE MAKER does not operate
