Slow Ice - Flex Tray I/M
• Thisproblemisusuallycausedbyadefectivesensororlowwaterpressure.TheI/M
sensorwill delathetime baddinextra fillsif the waterressure islow.Also check
theoperationofthefreezer,ifthefreezertemperatureisabove1.5 ,iceproduction
willbedelayed.Thiscanalsobecausedbyaproblemwiththefreezerairvent,make
suretheairductneartheicemakerisnotrestricted.IftheunitisonanR/Owater
sstem,water ressurema betolowforconsistentice roduction.
• Is there any frost in the freezer compartment?
• Excessive frost could mean warm air leaking into the compartment warming the top
of the freezer preventing the ice maker sensor from maintaining the necessary 1.5
.
•Check for ice chute failure, a leak at ice maker fill tube, an air leak around
defrost water drain by evaporator coil, cracks in liner or a bad door seal.
• Finally make sure the most updated version of Ice maker kit has been installed. The
ice maker designs in many models have been updated for better performance. Check
GSPN for any related service bulletins regarding Ice-maker changes.
