Samsung Refrigerator Technology Page 46

Workshop Manuals
Service Concerns-
•Troubleshooting Observations
•Is there an frost in the freezer comartment?
•Excessive frost on the evaporator coil will either coat the coil enough to
warm the air to 32 to supply the ice room or block the air duct
comletel to the ice room. Make sure the Freezer defrost circuit is
working properly and the freezer and ice room compartments are sealed
properly
•Theconsumercomlaintcouldbe“itonlmakesiceonceortwiceada”
TheIcemakerwillharvestwithinafewhoursof thefreezerdefrostcycle,
whentheevaporatorisfrostfree.Asthefrostbuildsuponthe
evaporatoragaintheicemakerwillstopasthetemperatureistoowarm.
Icemakingwillstopuntilthenextdefrostcyclecompleteswhichwillbe
12 to23hours later.Thisis adefrost error notan icemaker error.Check
thefreezerdoorseal,iceroomdoorsealandthefreezerdefrostheater.
