Door Removal – French Door Model
3. Remove the 3 hex head bolts
⑦
found
attached to the upper left and right door
hinges with a Wrench (10mm).
With a Philips head screwdriver, remove the
ground screw ⑧found attached to the upper
left and right door hinges. Remove the upper
⑦
4. Lift the door straiht u to remove.
left and right door hinges ⑨.
Refrigerator Refrigerator
⑧
5. With a Philips head screwdriver, remove the
2 screws
⑩
attached to the lower left and
right door hinges. With a Wrench (10mm),
remove the 2 hex head bolts
⑪
attached to the
lower left and right door hinges. Remove
⑫
77
te ower e t an rgt oor nge .
