Samsung Refrigerator Technology Page 69

Workshop Manuals
Refrigerator Truck Stock Recommendations
• The recommended The recommended truck stock truck stock items list updated items list updated bi-bi- monthly please monthly please check the check the TechTech
Talk Newsletter for the most updated listingTalk Newsletter for the most updated listing
( ( ) ) = = Stock Stock QuantityQuantity
(4) DA47-10160H Bi-Metal to replace all Thermal Fuses
(1) DA67-00466B Water Filter Bypass Cap (used to verify filter operation)
-
(2)DA73-30102E Drier
(2) DA73-30102F Drier
(1)DA31-00010C (DA31-00015A, DA31-00015B, DA31-00015C, DA31-00010D,
-
(1) MK183CL2U/E01 (MK183CL2U/E07) Compressor
Defrost Sensor Common Part Number Defrost Sensor Common Part Number
(4) DA32-00006W --Defrost Sensor with longest wires
Note:Note: Replacement refrigerator water filters will no longer be considered a service
item and will exclusively be handled by Samsung sales and marketing groups.
85
