Samsung Refrigerator Technology Page 8

Workshop Manuals
Refrigeration Troubleshooting
•Forced Defrost Operation
•Standard compressor models can activate the Fridge
defrost only, or both the Fridge and Freezer defrost.
•Invertercompressormodelsactivateallheatersatonce.
controls the heater operation. When defrost is activated
the main PCB will turn over defrost control to the sensor
in about 90 seconds. If the defrost sensor reads a
temperature above the shut off point it will tell the main
PCB to turn off the defrost voltae.
•Even when the defrost is turned off the unit will stay in
the forced mode for up to 24 hours.
24
