Shattered Ice Cubes -Flex Tray I/M
• When all ice shatters it's because of a bad tray or harvesting at a temp that is too
cold (lower than 1.5 ), in some areas hard water issues that can also cause
shattered cubes. The temp in the freezer should not have any effect on this issue, as
long as it’s below 1.5 , as a properly installed sensor will not read the freezer temp,
only the water/ice temp.
• Check the Ice tray for defects in the plastic. Impurities or hard water can cause the
plastic to become rough and inhibit the ice falling from the tray during the twisting. If
this is the case, relace the tra assembl.
• It is possible to get ice too cold. Ice that is too cold will shatter during harvest.This
can be from the (1) sensor not reading the correct temp (2) the sensor not mounted
correctly (3) by programming the icemaker offset value to a lower number (4) the
.
• To check the sensor you must check the tray temp (not air temp)and compare it to
the sensor reading. The sensor should read about 3.7VDC at the main board
connector when the cube temperature is 5 degrees. After the fill the sensor will read
. . .
• To clear offsets, put unit into Diagnostics mode.
• Please note, some shattering is normal for a flex tray icemaker, especially if the Ice
Off feature was used recently.
61
