Samsung Refrigerator Technology Page 54

Workshop Manuals
Defrost Service
nge vaporator oes
•Frost/Ice forming on the evaporator cover and blocking fan and air
tunnel to fridge.
–Install Repair Kit for Serial Number range: up to **42BL3*****
Units manufactured before April of 2006 For model RS2630
–Check for ice chute failure, leak at ice maker fill tube, air leak
around defrost water drain by evaporator coil, cracks in liner, or
door seal on fridge or freezer.
–Excessive door openings, doors left open for long periods, hot
foods put in fridge
Evaporator frozen, solid ice
Evaporator frozen, all frost
•Bad defrost sensor, open thermal fuse, bad main PCB, open defrost
70
heater
