Samsung Refrigerator Technology Page 71

Workshop Manuals
Resistance(Voltage Resistance Voltage Temp. Resistance Voltage
Sensor Test Chart
Temp. (
)
)
(V) Temp. (
)
()
(V) (
)
()
(V)
-43.6 98.9 4.54 12.2 21.4 3.41 68.0 6.01 1.88
-41.8 93.7 4.52 14.0 20.5 3.36 69.8 5.79 1.83
-40.0 88.9 4.49 15.8 19.6 3.31 71.6 5.58 1.79
-38.2 84.2 4.47 17.6 18.7 3.26 73.4 5.38 1.75
-36.4 79.8 4.44 19.4 17.9 3.21 75.2 5.19 1.71
-34.6 75.7 4.42 21.2 17.2 3.16 77.0 5.00 1.67
-32.8 71.8 4.39 23.0 16.4 3.11 78.8 4.82 1.63
-31.0 68.2 4.36 24.8 15.7 3.06 80.6 4.65 1.59
-29.2 64.7 4.33 26.6 15.1 3.01 82.4 4.49 1.55
-27.4 61.5 4.30 28.4 14.5 2.96 84.2 4.33 1.51
-25.6 58.4 4.27 30.2 13.9 2.90 86.0 4.18 1.47. . . . . .. . .
-23.8 55.6 4.24 32.0 13.3 2.85 87.8 4.03 1.44
-22.0 52.8 4.20 33.8 12.7 2.80 89.6 3.89 1.40
-20.2 50.2 4.17 35.6 12.2 2.75 91.4 3.76 1.37
-18.4 47.8 4.13 37.4 11.7 2.70 93.2 3.63 1.33
16.6 45.5 4.10 39.2 11.3 2.65 95.0 3.51 1.30
--
. . . . . .. . .
-13.0 41.2 4.02 42.8 10.4 2.55 98.6 3.28 1.23
-11.2 39.2 3.99 44.6 10.0 2.50 100.4 3.17 1.20
-9.40 37.4 3.95 46.4 9.60 2.45 102.2 3.06 1.17
-7.60 35.7 3.91 48.2 9.20 2.40 104.0 2.96 1.14
-5.80 34.0 3.86 50.0 8.80 2.35 105.8 2.86 1.11
-. .. . . . . . .
-2.20 30.9 3.78 53.6 8.20 2.25 109.4 2.68 1.06
-0.40 29.5 3.73 55.4 7.90 2.20 111.2 2.59 1.03
1.40 28.1 3.69 57.2 7.60 2.15 113.0 2.51 1.00
3.20 26.9 3.64 59.0 7.30 2.10 114.8 2.43 0.98
5.00 25.7 3.60 60.8 7.00 2.06 116.6 2.35 0.95
87
6.80 24.5 3.55 62.6 6.70 2.01 118.4 2.28 0.93
8.60 23.4 3.50 64.4 6.50 1.97 120.2 2.21 0.90
10.4 22.4 3.46 66.2 6.20 1.92
Table ATable A
